Medium and High Voltage Soft Start Cabinet
-Motor Power Range: 200kW to 10MW
-Voltage Level: 3.3kV to 11kV
-Start Method: Voltage Ramp, Current Limit
-Protection Features: Phase Imbalance, Motor Stall
-Cooling System: Forced Air Cooling
- Overview
- Recommended Products
Product Brief Description:
This cabinet reduces mechanical stress and inrush current during motor startup in medium/high-voltage applications. It ensures smooth acceleration and protects equipment from abrupt power surges.
Parameter Specification:
Parameter |
Specification |
Motor Power Range |
200kW to 10MW |
Voltage Level |
3.3kV to 11kV |
Start Method |
Voltage Ramp, Current Limit |
Protection Features |
Phase Imbalance, Motor Stall |
Cooling System |
Forced Air Cooling |
Warranty |
1 year |
Key Features:
Gradual Acceleration: Customizable startup curves for diverse motor types.
Energy Savings: Reduces peak current demand by up to 70%.
Robust Protection: Integrated surge arrestors and thermal sensors.
User Interface: Touchscreen HMI for parameter configuration and diagnostics.
Applications:
Large pumps and compressors in oil refineries
Mining conveyor systems
Water treatment plant motors
